Engine

Single Cylinder, 4-stroke, Air Cooling Engine

Displacement

107cc

Max Power

4.6/4.9Kw/7500r/min±375 r/min

Max Torque

6.8/7.0Nm/5500r/min±250r/min

Compression Ratio

9.0:1

Ignition

CDI

Start

Electric

Transmission

4 Speed Manual

Clutch

Wet Multi-plate Type

Lubrication

Pressure Splash

Dimension

1940×700×1240mm

Wheel Base

1270mm

Weight

95Kg

Max Load Capacity

150Kg

Max Speed

85Km/h

Tyres

Front 2.50-17-4PR, Rear Drum 2.75-17-6PR

Brakes

Front Disc, Rear Drum

Battery

12V·6.5A·h

fuel tank

3.5L

Loading Information

Capacidad

20′

40′GP

40′HQ

CBU

CKD
