Engine

Single Cylinder, 4-stroke, Air Cooling Engine

Displacement

107cc

Max Power

4.6/4.9Kw/7500r/min±375 r/min

Max Torque

6.8/7.0Nm/5500r/min±250r/min

Compression Ratio

9.0:1

Ignition

CDI

Start

Electric/Kick Start

Transmission

4 Speed Manual

Clutch

Wet Multi-plate Type

Lubrication

Pressure Splash

Dimension

1870×690×1250 mm

Wheel Base

1230mm

Weight

95kg

Max Load Capacity

150kg

Max Speed

75Km/h

Tyres

Front 2.50—17—4PR, Rear Drum 2.75—17—6PR

Brakes

Front Drum, Rear Drum

Battery

12V 5A·h

fuel tank

3.5L

Loading Information

Capacidad

20′

40′GP

40′HQ

CBU

CKD
