Engine

Single Cylinder, 4-stroke, Air Cooling Engine

Displacement

107ml

Max Power

5.0kw/7500r/min

Max Torque

7.2N·m/5000r/min

Compression Ratio

9.0:1

Ignition

CDI

Start

Electric/Kick Start

Transmission

4 Speed Manual

Clutch

Wet Multi-plate Type

Lubrication

Pressure Splash

Dimension

1900×700×1090mm

Wheel Base

1280mm

Weight

93kg

Max Load Capacity

150kg

Max Speed

75km/h

Tyres

Front 2.25-17, Rear Drum 2.75-14

Brakes

Front Disc, Rear Drum

Battery

12V 5A·h

Loading Information

Capacidad

20′

40′GP

40′HQ

CBU

105

CKD

173
