Engine

Single Cylinder, 4-stroke, Air Cooling Engine

Displacement

119.7cc

Max Power

5.8/ 6.1Kw/7500r/min±375 r/min

Max Torque

8.5/ 8.9Nm/5500r/min±250r/min

Compression Ratio

9.0:1

Ignition

CDI

Start

Electric/Kick Start

Transmission

4 Speed Manual

Clutch

Automatic Clutch

Lubrication

Pressure Splash

Dimension

1960×690×1140 mm

Wheel Base

1310 mm

Weight

93kg

Max Load Capacity

150kg

Max Speed

91km/h

Tyres

Front 2.25-17, Rear Drum 80/100-14

Brakes

Front Disc, Rear Drum

Battery

12V 5A·h

Loading Information

Capacidad

20′

40′GP

40′HQ

CBU

105

CKD

168
